Wide-belt sander Maxx 4 1100

Original construction of the series Maxx 4 has been developed for customers who require simplicity, reliability and quality for all technologies of sanding. Metal sanding is very easy task for this machine.

Maxx 4 excels in its robustness, reliability and variable combination of sanding units. Main advantage of wide belt sanders Maxx is satisfaction and reliability of thousands of customers proven worldwide.

Machine benefits

2011
We produce the machine since 2011
11
We delivered the machine to 11 of the world's countries
60
We produced the machine for 60 of satisfied customers
combines 3 different types of working units (drum brush B, disc brush D, grinding roller R) combines 3 different types of working units (drum brush B, disc brush D, grinding roller R)
sanding belt length is 1900 mm - optional  2200 mm sanding belt length is 1900 mm - optional 2200 mm
working rolls diameter is 120 mm working rolls diameter is 120 mm
workpiece thickness 0,5 - 160 mm workpiece thickness 0,5 - 160 mm
sand up to 1100 mm wide material sand up to 1100 mm wide material
11 - 15 kW for unit R, 11 kW for unit B, 1,5 kW for unit D 11 - 15 kW for unit R, 11 kW for unit B, 1,5 kW for unit D

Use

Wide belt sanders Maxx 6W series are designed for sanding (machining) workpieces from metal.

Interesting product

  • Universal machine with variety of working units, proved robust contruction.

Specifications

Sanding belt width 1 120 mm
Sanding belt length 1 900 mm
Table stroke 220 mm
Shaft diameter 60 mm
Motor power RB 1100 11 a 11 kW
Motor power RRB 1100 2 x 11 a 11 kW
Motor power RBB 1100 11 a 2 x 11 kW
Motor power RBR 1100 2 x 11 a 11 kW
Motor power RDB 1100 11 a 1,5 a 11 kW
Motor power RBD 1100 11 a 1,5 a 11 kW
Motor power R 1100 7,5 a 11 kW
Motor power RR 1100 2 x 7,5 a 2 x 15 kW
Motor power RRR 1100 3 x 7,5 a 3 x 11 kW
Motor power RD 1100 11 a 2,2 kW
Motor power RRD 1100 2 x 11 a 1,5 kW
Motor power RDR 1100 2 x 11 a 1,5 kW
Motor power RDD 1100 11 a 2 x 1,5 kW

3D Model

0%

    Standard equipment

    • rubbered roller D=120 mm, 60 Sh
    • sanding belt speed 18 m/s
    • sanding belt dimensions 430x1900 mm, 830x1900 mm, 1120x1900 mm, 1330x1900 mm
    • motorized table height adjustment
    • min./max. workpiece height 0,5/160 mm
    • automatic star/delta switch
    • feed belt motor frequency inverter- speed 2-10 m/min
    • ammeter for motor of sanding unit
    • optical sensor control of abrasive belt oscillation
    • electronic measuring of table position with digital display
    • rubber pressure rollers with covered quides
    • main motor pneumatic disc brake
    • pressure switch 3,5-4,0 bar
    • sanding belt
    • CE certification

    Optional accessories
